AUGUST 160KW 215HP High Pressure Air Compressor

  • AUGUST 160KW 215HP High Pressure Air Compressor
  • AUGUST 160KW 215HP High Pressure Air Compressor
  • AUGUST 160KW 215HP High Pressure Air Compressor

AUGUST 160KW 215HP High Pressure Air Compressor

Product Description

AUGUST 160KW 215HP High Pressure Air Compressor


Product Description


  • Air Cooled
  • Twin Screw Single Stage Air End – August- Brand
  • 5 Year Rotor Warranty
  • 45,000-50,000 Working Hours Engineered Lifetime
  • Skf Explorer Bearings (Mainly)
  • Energy Saving Micro Control System, Fully Automated Operation
  • Easy Maintenance
  • Low-Noise Operation, Closed Cabinet Structure, Noise Reducing Dumping Mats Made Of Fire-Retardant Materials
  • Belt Drive
  • Drawing For Reference Only
  • Efficient, Safe And Reliable Fully Enclosed Motor Drive (Ip54, F Class / Ip55 Optional)
  • Energy Saving Air End 5:6 Helix
  • Networkable Link Between Compressors / Grouping With On-Line, Remote Monitoring And Dsc Network Functions
  • High Precision Heavy Duty Intake Filter 1Μm, 99.9% Efficiency
  • Optimized Oil Separation System Residual Oil Rate 1-3Mg/M3
  • Low Speed Air End Operation
  • Powerful Low Noise Exhaust Fan / On Top Exhaust
  • Automatic Control Of Functions / Maintenance Indicator
  • English Language Display, Easy Operation, Running Status At A Glance, Runningreal-Time Monitoring Data
  • Pressure And Temperature Control And Protection
  • Start Up Protection ( Current Spike Free)
  • English Language Display / English Language Manual
Model SF160A SF160B SF160C SF160D
Free air delivery(m3/min) 28.5 24.5 20.2 27.0
cfm 1006 865 713 953
l/s 475 408 337 450
Discharge pressure(MPa) 0.7 1.0 1.3 0.8
bar 7 10 13 8
psig 102 145 189 116
Ambient temperature(℃) -5~+40
Cooling method Air cooling
Air supply temperature (℃) Less Than Ambient temperature +15℃
Drive method Direct Coupling Drive
Start method Star delta start
Noise dB(A)±3 80
Power (kW/HP) 160/215
Overall dimension (mm) 2500×1450×2000
Weight (kg) 3500
Air supply out (Inch) 2 1/2"


IE3 Version Compliance:


Motor Power

(kw)

15 18.5 22 30 37 55 75 90 110 132 160 185 200 220 250


Efficiency


92.1 92.6 93 93.6 93.7 94.3 94.7 95.2 95.4 95.6 95.8 95.7 95.8 95.8 95.8


Company Information





High efficiency, energy saving and noise reduction elements are standard aspects in development and

production. The main product line reaches the standard of national Class 2 high efficiency requirements.

Furthermore Heat recovery systems, permanent magnet motor technology and VSD Inverter applications

are available to provide an even higher efficiency of the compressors. We combine the advanced

German technologies with the latest research achievement and rely on the core technology we own,

to establish our leading position in the industry and provide advanced solution to compressed air system

for customers in and outside China.



Product according with National Class II Energy-saving product, CE Marking Product Quality, ASME
available,ISO9001,ISO14001,ISO1217,OEM Welcome and adaptation to country specific regulations,
voltage and frequency are available. AUGUST Screw Air Compressor the best choice for your ROI.
Place your inquiry for more details or request for dealership in selected regions.


Ningbo Xinda Screw Compressor Co., Ltd.

 NINGBO XINDA SCREW COMPRESSOR CO., LTD.was founded in 1998,is a modern screw compressor specialized production enterprise,which has the core technology of Screw Air Compressor,has full independent intellectual property rights,and by the strict review licensing screw Air Compressor manufacturing base.The factory covers an area of 200,000 square meters,a building area of 120,000 square meters and a total staff of more than 1,300, among which more than 300 professional and technical personnel. After more than 20 years of development,company accumulated rich experience in compressor design and manufacturing,has a strong R&D team, specialized in efficient and perfect compressed air system solutions,constantly improveing products performance and manufacturing process. Specializing in the production of AUGUST screw compressor,at present has XGT/XPT series-two stage compression regular pressure compressor EGT/EPT series-two stage compression compressor for textile industry SF/SF-T series-single stage compression compressor MP series-permanent magnet variable frequency compressor YGS series-all in one compressor, HPS series-speial for laser cutting all in one compressor WG(P)S/WHPS series-water lubrication oil free regular pressure and high pressure compressor LG(P)S series-single stage 3 bar low pressure compressor Special for industrial and mining compressor Quality performance reached the international advanced level,products industries all over the country,and exported to Europe,southeast Asia,Middle East and other regions,favored by users.Adhering to the business tenet of [high efficiency, energy saving, reliability and durable"AUGUST provide you with high-quality products and services as well as customized Air compressor system solutions.
